76570EM 41
20-6．Shooting, Playback Function
Never install or remove the CF card while turning the camera’s power ON as this may cause the
CF card or camera to be damaged and become unusable.
*When replacing T100, confirm this section after adjusting [ADJUSTMENT WITH
PROGRAMMED SOFTWARE (SLR OPERATION)]
(1) Turn the main SW to OFF and insert the CF card (for Taking picture) into the camera.
(2) Turn the main SW ON
(3) Press the MENU button and format the SD card according to indication of
LCD monitor.
(4) Set the Quality level and Recorded pixels to the default setting and
take three pictures. (Quality Level: ★★★, Recorded Pixels: 6M)
(5) Press the Playback button and confirm the image quality.
(6) When the INFO button is pressed during playback, the camera must switch from
Normal Playback Screen to Histogram Display.
(7) When the INFO button is pressed again, the camera must switch from Histogram
Display to Detailed Information display.
(8) Press the Delete button twice, and then delete all images by the four-way controller key and
OK button.
(9) Turn the main SW to OFF and remove the CF card from the camera.
20-7. Flash function
(1) The built-in flash pops up when the flash button is pressed. And, must be appeared in the
viewfinder and on the LCD panel when flash is fully charged.
(2) The flash must be discharged when taking a picture in low light condition, also the built-in
flash must be retracted firmly when flush is pushed down by finger.
* If flash does not retract properly, follow the [Adjustment of flash retract position].
(3) Confirm that must be appeared and discharged when an external flash is attached.
20-8．Adjustment of flash retract position
Preparation: Hexagonal driver 0.9mm (HD-M0.9)
(1) There should be less than 0.3mm between A and B when push down the flash.
(2) It can be adjusted by turning the adjusting screw, refer to the picture.
(3) Apply screw lock to the adjusting screw
a
b
L
(2)
(3)
Less than 0.3mm
a b
①
