Pentax Q7 User Manual

1
Introduction
11
tMemo
• Items that can be selected vary depending on the current
camera setup.
• If no operations are made within 1 minute while the control
panel is displayed, the camera will return to standby mode.
• You can change the display color of the control panel and
menus in [LCD Display] of the D1 menu. (p.18)
If you press G while the control panel is displayed, you can
select the type of information displayed in standby mode. Use
CD to select the type and press E.
uCaution
• [Display Off] cannot be selected in C mode.
The captured image and shooting information are displayed in
single image display of the playback mode.
Press G to select the type of information displayed in single
image display. Use CD to select the type and press E.
tMemo
• The screen selected in Playback Info Display selection screen
is displayed in playback mode when the camera is turned off
and on again. If [Playback Info Display] is set to [Off] in
[Memory] of the
A 3 menu, the [Standard Information Display]
always appears first when the camera is turned on. (p.65)
16 JPEG Recorded Pixels
and Quality Level (p.43)/
Movie Recorded Pixels
(p.43)
20 Recording Sound Level
21 Destination (p.64)
22 Current date and time
23 Memory card
17 Shake Reduction/Movie
SR
24 Number of recordable
still pictures/movie
recordable time
18 Exposure Setting
19 Framerate
Shooting Info Display
Standard
Information Display
An image and the current shooting
function settings are displayed.
No Information
Display
Only an image is displayed.
Display Off Nothing is displayed on the monitor.
Playback Mode
Standard
Information Display
Captured image, file format, exposure value,
and operation guide indicators are displayed.
Detailed
Information Display
Detailed information on how and when the
image was taken is displayed. (p.12)
Histogram
Display
Captured image and brightness
histogram are displayed. (p.12)
Not available during movie playback.
RGB Histogram
Display
Captured image and RGB histogram are
displayed. (p.12)
Not available during movie playback.
No Information
Display
Only the captured image is displayed.
G
1/
2000
1/
2000
F2.8
F2.8
200
200
+0.3
+0.3
100-0001
100-0001
Standa rd Inf ormati on Dis play
Standard Information Display
1/
2000
1/
2000
F2.8
F2.8
200
200
+0.3
+0.3
100-0001
100-0001
Single image display
(Standard Information Display)
Playback Info Display
selection screen

Pentax Q7 Specifications

General

Megapixel	12.4 MP
Camera type	MILC Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.76 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Image stabilizer location	Body
Still image resolution(s)	JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax Q
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Contrast Detection Auto Focus
Auto Focus (AF) points selection	Auto, Manual
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Shutter speed settings	B
Camera shutter interval	3 s
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash guide number	4.9 m
Flash exposure correction	-2EV - +1EV (1/2 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	Eye-Fi, SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Yellow
Scene modes	Backlight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Muted, Neutral
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 12 s
Languages support	CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3, RAW
Playback zoom (max)	16 x
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery type	D-LI68
Battery life (CIPA standard)	260 shots
Cables included	USB
Bundled software	SILKYPIX Developer Studio 3.0 LE

Weight and Dimensions

Depth	33.5 mm
Width	102 mm
Height	58 mm
Weight	180 g
Weight (including battery)	200 g
