Appendix
Vignetting will occur at the wide-angle setting if a PL100 filter is
used with a 02 STANDARD ZOOM lens.
A K-mount lens can be attached to this camera with the use of
the optional Adapter Q for K Mount Lens. When a K-mount lens
is used, the focal length must be set manually for some
functions such as Shake Reduction, since the focal length
cannot be obtained automatically.
1 Turn the camera off.
2 Attach the adapter and lens to the camera, and
turn the camera on.
The [Input Focal Length] screen appears.
3 Set the lens focal length.
Available operations
When using a zoom lens, select the actual focal length
which the zoom is set to.
4 Press E.
The camera returns to standby mode.
tMemo
• The focal length setting can be changed in [Input Focal
Length] of the A2 menu.
• When the Adapter Q for K Mount Lens is used, the camera
operates in J mode when the capture mode is set to other
than L mode.
• Refer to the Adapter Q for K mount lens manual for details.
About Filters
Using a K-Mount Lens
AB Changes the value of each digit.
CD Selects a digit.
V Selects a value from the list.
Cancel
Cancel
Input Focal Length
Input Focal Length
300.0
300.0
200.0
200.0
135.0
135.0
77.0
77.0
55.0
55.0
35.0
35.0
21.0
21.0
15.0
15.0
OK
OK
OK
MENU
00 00 .0
0000.0
mm
mm

Pentax Q7 Specifications

General

Megapixel	12.4 MP
Camera type	MILC Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.76 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Image stabilizer location	Body
Still image resolution(s)	JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax Q
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Contrast Detection Auto Focus
Auto Focus (AF) points selection	Auto, Manual
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Shutter speed settings	B
Camera shutter interval	3 s
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash guide number	4.9 m
Flash exposure correction	-2EV - +1EV (1/2 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	Eye-Fi, SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Yellow
Scene modes	Backlight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Muted, Neutral
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 12 s
Languages support	CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3, RAW
Playback zoom (max)	16 x
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery type	D-LI68
Battery life (CIPA standard)	260 shots
Cables included	USB
Bundled software	SILKYPIX Developer Studio 3.0 LE

Weight and Dimensions

Depth	33.5 mm
Width	102 mm
Height	58 mm
Weight	180 g
Weight (including battery)	200 g
