Pentax Q7 User Manual

3
Shooting
40
1 Press D in standby mode.
The Drive Mode screen appears.
2 Use CD to select O and
press B.
3 Use CD to select O or P and press E.
The camera returns to standby mode.
4 Press the shutter release button halfway  fully.
The self-timer lamp blinks.
The shutter will be released about 12 seconds or 2
seconds.
1 Press D in standby mode.
The Drive Mode screen appears.
2 Use CD to select Q and
press B.
3 Use CD to select Q, R or S and press E.
The camera returns to standby mode.
The self-timer lamp blinks.
4 Press the shutter release button halfway.
5 Point the remote control unit towards the remote
control receiver on the front or back of the
camera, and press the shutter release button on
the remote control unit.
tMemo
• The maximum operating distance of the remote control unit is
approx. 4 m from the front of the camera and approx. 5 cm
from the back of the camera.
• To use the remote control unit to adjust the focus, set in [9.
AF with Remote Control] of the E2 menu.
• When using the Remote Control Waterproof O-RC1, the
autofocus system can be operated with the q button. The r
button cannot be used.
Self-timer Shooting
Self-t imer ( 12 sec. )
Self-timer (12 sec.)
Cancel
Cancel
OK
OK
OK
MENU
Remote Control Shooting
Remote Contr ol
Remote Control
Cancel
Cancel
OK
OK
OK
MENU

Pentax Q7 Specifications

General

Megapixel	12.4 MP
Camera type	MILC Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.76 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Image stabilizer location	Body
Still image resolution(s)	JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax Q
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Contrast Detection Auto Focus
Auto Focus (AF) points selection	Auto, Manual
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Shutter speed settings	B
Camera shutter interval	3 s
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash guide number	4.9 m
Flash exposure correction	-2EV - +1EV (1/2 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	Eye-Fi, SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Yellow
Scene modes	Backlight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Muted, Neutral
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 12 s
Languages support	CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3, RAW
Playback zoom (max)	16 x
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery type	D-LI68
Battery life (CIPA standard)	260 shots
Cables included	USB
Bundled software	SILKYPIX Developer Studio 3.0 LE

Weight and Dimensions

Depth	33.5 mm
Width	102 mm
Height	58 mm
Weight	180 g
Weight (including battery)	200 g
