Pentax Q7 User Manual

6
Appendix
78
Model Description
Image Capture Unit
File Format
Monitor
White Balance
Focusing Mechanism
Main Specifications
Type Lens-interchangeable SL digital camera
Lens Mount PENTAX bayonet Q-mount
Compatible Lens Q-mount lenses
Image Sensor
Type: CMOS sensor with a primary color filter
Size: 1/1.7-inch
Effective Pixels Approx. 12.4 megapixels
Total Pixels Approx. 12.76 megapixels
Dust Removal
Image sensor cleaning using ultrasonic vibrations
“DR II”
Sensitivity
(Standard Output)
ISO AUTO: ISO 100 to ISO 12800 (1/3 EV steps)
• Up to ISO 1600 when the shutter speed is set to 2
sec. or slower.
Image Stabilizer Sensor shift Shake Reduction
Recording
Formats
RAW (DNG), JPEG (Exif 2.3), DCF 2.0 compliant
Recorded Pixels
JPEG: yq9M (4000×2248)
p 5M (3072×1728)
o 2M (1920×1080)
xq10M (4000×2664)
p 6M (3072×2048)
o 2M (1920×1280)
wq12M (4000×3000)
p 7M (3072×2304)
o 3M (1920×1440)
vq9M (2992×2992)
p 5M (2304×2304)
o 2M (1440×1440)
RAW: wq12M (4000×3000)
Quality Level
RAW: DNG (12 bit)
JPEG: m (Best), l (Better), k (Good)
• RAW and JPEG simultaneously recordable
Color Space sRGB, AdobeRGB
Storage Media
SD Memory Cards, SDHC Memory Cards, SDXC
Memory Cards and Eye-Fi Cards
Storage Folder
Date (100_1018, 100_1019...)/
PENTX (100PENTX, 101PENTX...)
Type
TFT color LCD monitor, wide angle viewing, with AR
coating
Size 3.0 inches
Dots Approx. 460,000 dots
Adjustment Brightness and colors adjustable
Display
Field of View: approx. 100%, Electronic Level, Grid
Display (4 × 4 Grid, Golden Section, Scale),
Highlight Alert, Histogram
Auto TTL by CMOS image sensor
Preset
Daylight, Shade, Cloudy, Fluorescent Light (D:
Daylight Color, N: Daylight White, W: Cool White, L:
Warm White), Tungsten, Flash, n, Manual
Manual
Configuration on monitor (3 types can be saved),
configuration on captured image
Fine Adjustment Adjustable ±7 steps on A-B axis and G-M axis
Type Contrast detection AF
Brightness Range EV 0 to 18 (ISO100)
Focus Method v/w switching
Autofocus Method
Face Detection, Tracking, Multiple AF Points (49
Points), Select, Spot
AF Assist Light Dedicated LED AF assist light

Pentax Q7 Specifications

General

Megapixel	12.4 MP
Camera type	MILC Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.76 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Image stabilizer location	Body
Still image resolution(s)	JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax Q
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Contrast Detection Auto Focus
Auto Focus (AF) points selection	Auto, Manual
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Shutter speed settings	B
Camera shutter interval	3 s
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash guide number	4.9 m
Flash exposure correction	-2EV - +1EV (1/2 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	Eye-Fi, SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Yellow
Scene modes	Backlight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Muted, Neutral
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 12 s
Languages support	CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3, RAW
Playback zoom (max)	16 x
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery type	D-LI68
Battery life (CIPA standard)	260 shots
Cables included	USB
Bundled software	SILKYPIX Developer Studio 3.0 LE

Weight and Dimensions

Depth	33.5 mm
Width	102 mm
Height	58 mm
Weight	180 g
Weight (including battery)	200 g
