6
Appendix
90
The AC plug cord provided with this camera is developed exclusively for
the battery charger D-BC68P. Do not use it with other devices.
Do not subject the camera to high temperatures or high humidity. Do not
leave the camera in a vehicle, as the temperature can get very high.
Do not subject the camera to strong vibrations, shocks, or pressure. Use
a cushion to protect the camera from vibrations of motorcycles,
automobiles, or ships.
The temperature range for camera use is 0°C to 40°C (32°F to 104°F).
The monitor may appear black at high temperatures, but will return to
normal at normal temperatures.
The monitor may respond more slowly at low temperatures. This is due
to liquid crystal properties, and is not a malfunction.
Sudden temperature changes will cause condensation on the inside and
outside of the camera. Place the camera in your bag or a plastic bag,
and remove it after temperatures of the camera and surroundings are
equalized.
Avoid contact with garbage, mud, sand, dust, water, toxic gases, or salt.
These could cause the camera to breakdown. Wipe the camera to dry
off any rain or water drops.
Do not press the monitor with excessive force. This could cause it to
break or malfunction.
Be careful not to overtighten the screw in the tripod socket when using
a tripod.
Do not clean the camera with organic solvents such as thinner, alcohol,
and benzine.
Use a lens brush to remove dust accumulated on the lens. Never use a
spray blower for cleaning as it may damage the lens.
Please contact your nearest service center for professional cleaning of
the CMOS sensor. (This will involve a fee.)
Periodic inspections are recommended every one to two years to
maintain high performance.
Do not store the camera with preservatives or chemicals. Storage in high
temperatures and high humidity can cause mold to grow on the camera.
Remove the camera from its case and store it in a dry and well-ventilated
place.
Avoid using or storing the camera where it may be exposed to static
electricity or electrical interference.
Avoid using or storing the camera in direct sunlight or in locations where
it may be exposed to rapid changes in temperature or to condensation.
The SD Memory Card is
equipped with a write-protect
switch. Setting the switch to
LOCK prevents new data from
being recorded on the card, the
stored data from being deleted,
and the card from being
formatted by the camera or
computer.
The SD Memory Card may be
hot when removing the card immediately after using the camera.
Do not remove the SD Memory Card or turn off the power while the card
is being accessed. This may cause the data to be lost or the card to be
damaged.
Do not bend the SD Memory Card or subject it to violent impact. Keep it
away from water and store away from high temperatures.
Do not remove the SD Memory Card while formatting. The card may be
damaged and become unusable.
Data on the SD Memory Card may be deleted in the following
circumstances. We do not accept any liability for data that is deleted if
1. the SD Memory Card is mishandled by the user.
2. the SD Memory Card is exposed to static electricity or electrical
interference.
3. the SD Memory Card has not been used for a long time.
4. the SD Memory Card or the battery is removed while the card is being
accessed.
If the SD Memory Card is not used for a long time, the data on the card
may become unreadable. Be sure to regularly make a backup of
important data on a computer.
Precautions on Carrying and Using Your Camera
Cleaning Your Camera
Storing Your Camera
About SD Memory Cards
Write-protect
switch

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pentax Q7 and is the answer not in the manual?

Pentax Q7 Specifications

General IconGeneral
Megapixel12.4 MP
Camera typeMILC Body
Sensor typeCMOS
Image stabilizerYes
Total megapixels12.76 MP
Image sensor size1/1.7 \
Image formats supportedJPG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Image stabilizer locationBody
Still image resolution(s)JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfacePentax Q
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesContrast Detection Auto Focus
Auto Focus (AF) points selectionAuto, Manual
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Auto, Manual
ISO sensitivity (max)12800
ISO sensitivity (min)100
Light exposure correction± 3EV (1/3EV step)
Camera shutter typeElectronic
Shutter speed settingsB
Camera shutter interval3 s
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed30 s
Flash modesRed-eye reduction, Slow synchronization
Flash guide number4.9 m
Flash exposure correction-2EV - +1EV (1/2 EV step)
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Memory slots1
Internal memory- MB
Compatible memory cardsEye-Fi, SD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)460000 pixels
USB version2.0
Product colorYellow
Scene modesBacklight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsMuted, Neutral
White balanceAuto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modesAperture priority, Auto, Manual, Shutter priority
Camera playbackMovie, Single image
Self-timer delay2, 12 s
Languages supportCHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file systemDCF 2.0, Exif 2.3, RAW
Playback zoom (max)16 x
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery typeD-LI68
Battery life (CIPA standard)260 shots
Cables includedUSB
Bundled softwareSILKYPIX Developer Studio 3.0 LE
Weight and Dimensions IconWeight and Dimensions
Depth33.5 mm
Width102 mm
Height58 mm
Weight180 g
Weight (including battery)200 g
