3
Shooting
32
tMemo
Exposure Bracketing shooting enables you to take pictures
while automatically changing exposure. (p.41)
A proper exposure may not be obtained with the selected
shutter speed and aperture value when the sensitivity is set
to the fixed value.
•In L mode, the difference from the proper exposure is
displayed in the EV bar scale while the shutter speed or
aperture value is adjusted.
You can set the function of the M button for when the camera
is in L/K mode. Set in [Green Button] of the A3 menu.
(p.63)
Sensitivity values higher than ISO 1600 are not available
when the shutter speed is set to 2 seconds or slower in I/
L mode.
1 Set the mode dial to L.
2 Turn V to the left.
V appears after the slowest
shutter speed.
3 Press the shutter release button.
The shutter remains open as long as the shutter release
button is kept pressed (up to 30 seconds).
4 Take your finger off the shutter release button.
Exposure ends.
uCaution
Bulb shooting is available only when using a lens that has a
lens shutter. (p.72)
Some functions cannot be used in this mode. (p.69)
1 Set the mode dial to C.
Use V and J to adjust the
exposure compensation value
when [Exposure Setting] of the
C1 menu is set to o.
2 Press the shutter release button halfway.
3 Press the shutter release button fully.
Movie recording starts.
R blinks at the top left of the screen.
When [Focus Method] is set to v, press E to perform
autofocus.
4 Press the shutter release button fully.
Movie recording stops.
Bulb Shooting
F2.8F2.8 16001600
3737
Checking the Depth of Field (Preview)
When [Preview] is assigned to M in [Green Button] of the
A2 menu, you can check the depth of field before taking
pictures. (p.62)
Movie Mode
10'30"
10'30"
Sound
Recordable Time

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pentax Q7 and is the answer not in the manual?

Pentax Q7 Specifications

General IconGeneral
Megapixel12.4 MP
Camera typeMILC Body
Sensor typeCMOS
Image stabilizerYes
Total megapixels12.76 MP
Image sensor size1/1.7 \
Image formats supportedJPG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Image stabilizer locationBody
Still image resolution(s)JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfacePentax Q
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesContrast Detection Auto Focus
Auto Focus (AF) points selectionAuto, Manual
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Auto, Manual
ISO sensitivity (max)12800
ISO sensitivity (min)100
Light exposure correction± 3EV (1/3EV step)
Camera shutter typeElectronic
Shutter speed settingsB
Camera shutter interval3 s
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed30 s
Flash modesRed-eye reduction, Slow synchronization
Flash guide number4.9 m
Flash exposure correction-2EV - +1EV (1/2 EV step)
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Memory slots1
Internal memory- MB
Compatible memory cardsEye-Fi, SD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)460000 pixels
USB version2.0
Product colorYellow
Scene modesBacklight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsMuted, Neutral
White balanceAuto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modesAperture priority, Auto, Manual, Shutter priority
Camera playbackMovie, Single image
Self-timer delay2, 12 s
Languages supportCHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file systemDCF 2.0, Exif 2.3, RAW
Playback zoom (max)16 x
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery typeD-LI68
Battery life (CIPA standard)260 shots
Cables includedUSB
Bundled softwareSILKYPIX Developer Studio 3.0 LE
Weight and Dimensions IconWeight and Dimensions
Depth33.5 mm
Width102 mm
Height58 mm
Weight180 g
Weight (including battery)200 g
