Pentax Q7 User Manual

2
Getting Started
22
Use the battery D-LI68 and battery charger D-BC68P
exclusively developed for this camera.
1 Connect the AC plug cord to the battery charger.
2 Plug the AC plug cord into the power outlet.
3 Face the A mark on the
battery up, and insert it
into the battery charger.
The indicator lamp is lit while
charging and turns off when the
battery is fully charged.
uCaution
• Do not use the battery charger D-BC68P to charge batteries
other than D-LI68. Charging other batteries may cause
damage or heating.
• Replace the battery with a new one in the following cases:
• If the indicator lamp blinks or does not light after the battery
is inserted correctly
•
If the battery starts to run down more quickly even after being
charged (the battery may have reached the end of its service life)
tMemo
• The maximum charging time is approximately 115 minutes (it
depends on temperature and remaining battery power).
Charge in a location where the temperature is between 0°C
and 40°C (32°F and 104°F).
uCaution
• Insert the battery correctly. If the battery is inserted
incorrectly, it may not be removed.
• Wipe the electrodes of the battery with a soft dry cloth before
inserting.
• Do not open the battery cover or remove the battery while the
power is on.
• Be careful as the camera or battery may become hot when
the camera is used continuously for a long period of time.
• Remove the battery when you will not use the camera for a
long time. The battery may leak and damage the camera if left
installed during prolonged periods of non-use. If the removed
battery will not be used for six months or longer, charge the
battery for about 30 minutes before storing it. Be sure to
recharge the battery every six to twelve months.
• Store the battery in a location where the temperature will
remain at or below room temperature. Avoid locations with
high temperatures.
Using the Battery and Charger
Charging the Battery
Indicator lamp
AC plug cord
Battery charger
Inserting/Removing the Battery

Pentax Q7 Specifications

General

Megapixel	12.4 MP
Camera type	MILC Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.76 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Image stabilizer location	Body
Still image resolution(s)	JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax Q
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Contrast Detection Auto Focus
Auto Focus (AF) points selection	Auto, Manual
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Shutter speed settings	B
Camera shutter interval	3 s
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash guide number	4.9 m
Flash exposure correction	-2EV - +1EV (1/2 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	Eye-Fi, SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Yellow
Scene modes	Backlight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Muted, Neutral
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 12 s
Languages support	CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3, RAW
Playback zoom (max)	16 x
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery type	D-LI68
Battery life (CIPA standard)	260 shots
Cables included	USB
Bundled software	SILKYPIX Developer Studio 3.0 LE

Weight and Dimensions

Depth	33.5 mm
Width	102 mm
Height	58 mm
Weight	180 g
Weight (including battery)	200 g
