Pentax Q7 User Manual

2
Getting Started
21
1 Make sure that the camera is turned off.
2 Remove the body mount
cover (1) and lens mount
cover (2).
After removing the cover, be sure
to put the lens down with the lens
mount side facing upward.
3 Align the lens mount index
(red dots: 3) on the
camera and the lens, and
secure by turning the lens
clockwise until it clicks.
To remove the lens
Attach the lens cap  turn the
lens counterclockwise while
pushing the lens unlock button
(4).
uCaution
• If the lens is removed while the power is on, the shutter
release button will be locked. Do not attach or remove the
lens while the power is on.
• When attaching or removing the lens, choose an environment
that is relatively free of dirt and dust.
• Keep the body mount cover on the camera when a lens is not
attached.
• Be sure to attach the lens mount cover and lens cap to the
lens after removing it from the camera.
• Do not insert your fingers inside the lens mount of the camera
or touch the CMOS sensor.
• The camera body and lens mount incorporate lens
information contacts. Dirt, dust, or corrosion may damage the
electrical system. Please contact your nearest service center
for professional cleaning.
• We assume no responsibility nor liability for accidents,
damages and malfunctions resulting from the use of lenses
made by other manufacturers.
Attaching a Lens
3
4

Pentax Q7 Specifications

General

Megapixel	12.4 MP
Camera type	MILC Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.76 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Image stabilizer location	Body
Still image resolution(s)	JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax Q
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Contrast Detection Auto Focus
Auto Focus (AF) points selection	Auto, Manual
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Shutter speed settings	B
Camera shutter interval	3 s
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash guide number	4.9 m
Flash exposure correction	-2EV - +1EV (1/2 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	Eye-Fi, SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Yellow
Scene modes	Backlight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Muted, Neutral
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 12 s
Languages support	CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3, RAW
Playback zoom (max)	16 x
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery type	D-LI68
Battery life (CIPA standard)	260 shots
Cables included	USB
Bundled software	SILKYPIX Developer Studio 3.0 LE

Weight and Dimensions

Depth	33.5 mm
Width	102 mm
Height	58 mm
Weight	180 g
Weight (including battery)	200 g
