6
77
Appendix
Not enough battery
power remaining to
activate Pixel Mapping
Appears during Pixel Mapping or when
trying to update the firmware if the battery
level is insufficient. Install a fully charged
battery.
Not enough battery
power remaining to
update the firmware
Unable to update firmware.
There is a problem with the
firmware update file
Unable to update the firmware. The
update file is damaged. Try downloading
the update file again.
Image folder cannot be
created
The maximum folder number (999) and
file number (9999) are being used, and no
more images can be saved. Insert a new
memory card or format the card.
Unable to store image
The image could not be saved because of
a memory card error.
Settings not stored
The DPOF settings could not be saved
because the memory card is full. Delete
unwanted images and perform DPOF
setting again. (p.68)
The operation could not be
completed correctly
The camera was unable to adjust the
manual white balance. Try the operation
again.
No more images
can be selected
You cannot select more than the
maximum number of images for Index,
Select & Delete, RAW Development,
Select image(s) for Eye-Fi, and DPOF.
No image can be processed
There are no images that can be
processed using Digital Filter or RAW
Development function.
Error Messages Description
This image cannot be
processed
Appears when you try to perform Resize,
Cropping, Red-eye Edit, Digital Filter,
Movie Edit, RAW Development, Save as
Manual WB, or Save Smart Effect for
images captured with other cameras, or
when you try to perform Resize or
Cropping for minimum file size images.
The camera failed
to create an image
The creation of an index print image
failed.
This function is not available
in the current mode
You are trying to set a function that is not
available for the capture mode that is set.
(p.69)
The camera will turn off
to prevent damage from
overheating
The camera will turn off because its
internal temperature gets too hot. Leave
the camera turned off until it has had time
to cool down before turning on the
camera again.
Set the Eye-Fi communication
to “SELECT”
Images cannot be transferred when [Eye-
Fi Communication] is not set to [SELECT]
in [Eye-Fi] of the D2 menu. (p.67)
Image not found
There are no images that can be
transferred when an Eye-Fi card is used.
Cannot be selected
This folder cannot be selected because
the number of files exceeds the maximum
number allowed. (p.67)
Error Messages Description

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pentax Q7 and is the answer not in the manual?

Pentax Q7 Specifications

General IconGeneral
Megapixel12.4 MP
Camera typeMILC Body
Sensor typeCMOS
Image stabilizerYes
Total megapixels12.76 MP
Image sensor size1/1.7 \
Image formats supportedJPG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Image stabilizer locationBody
Still image resolution(s)JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfacePentax Q
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesContrast Detection Auto Focus
Auto Focus (AF) points selectionAuto, Manual
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Auto, Manual
ISO sensitivity (max)12800
ISO sensitivity (min)100
Light exposure correction± 3EV (1/3EV step)
Camera shutter typeElectronic
Shutter speed settingsB
Camera shutter interval3 s
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed30 s
Flash modesRed-eye reduction, Slow synchronization
Flash guide number4.9 m
Flash exposure correction-2EV - +1EV (1/2 EV step)
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Memory slots1
Internal memory- MB
Compatible memory cardsEye-Fi, SD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)460000 pixels
USB version2.0
Product colorYellow
Scene modesBacklight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsMuted, Neutral
White balanceAuto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modesAperture priority, Auto, Manual, Shutter priority
Camera playbackMovie, Single image
Self-timer delay2, 12 s
Languages supportCHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file systemDCF 2.0, Exif 2.3, RAW
Playback zoom (max)16 x
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery typeD-LI68
Battery life (CIPA standard)260 shots
Cables includedUSB
Bundled softwareSILKYPIX Developer Studio 3.0 LE
Weight and Dimensions IconWeight and Dimensions
Depth33.5 mm
Width102 mm
Height58 mm
Weight180 g
Weight (including battery)200 g
