Pentax Q7 User Manual

3
Shooting
35
3 Press B, and use V to
compensate the flash
output.
Press M to reset the value.
4 Press E.
The camera returns to standby mode.
5 Slide the flash pop-up
switch.
uCaution
• Be sure to retract the built-in flash if not planning to use it. Be
careful not to get your fingers pinched when retracting the
flash.
• The built-in flash discharges even when retracted, which may
cause vignetting to occur depending on the lens being used.
If you do not want to let the built-in flash discharge while it is
retracted, set [11. Flash When Retracted] in the E2 menu.
• You cannot take pictures while the flash is being charged. If
you want to take pictures while charging the flash, set [12.
Release While Charging] in the E2 menu.
• Depending on the lens being used, the use of the built-in flash
may be limited. (p.72)
tMemo
• The flash modes that can be selected vary depending on the
capture mode.
*1 Fixed to J for some S modes.
• The built-in flash is optimum for a subject at a distance from
approx. 0.7 m to 5 m. Vignetting may occur when used at a
distance closer than 0.7 m (this distance varies slightly
depending on the lens being used and the sensitivity setting).
• For details on using an external flash, refer to “Functions
when Using an External Flash” (p.74).
Auto F lash D ischarg e
Auto Flash Discharge
Cancel
Cancel
OK
OK
OK
MENU
+0.7
+0.7
Capture Mode Selectable Flash Mode
R, S
*1
A, J
U A, B, C, D, J
G, J A, B, C, D, E, F, H, J
I A, B, C, D, G, J
L C, D, G, J
Sensitivity
Guide
Number
Sensitivity
Guide
Number
ISO 100 Approx. 4.9 ISO 1600 Approx. 20
ISO 200 Approx. 7 ISO 3200 Approx. 28
ISO 400 Approx. 10 ISO 6400 Approx. 40
ISO 800 Approx. 14 ISO 12800 Approx. 56

Pentax Q7 Specifications

General

Megapixel	12.4 MP
Camera type	MILC Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.76 MP
Image sensor size	1/1.7 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Image stabilizer location	Body
Still image resolution(s)	JPEG\\r [4:3]L:12M(4000x3000), M:7M(3072x2304), S:3M(1920x1440)\\r [3:2]L:10M(4000x2664), M:6M(3072x2048), S:2M(1920x1280)\\r [16:9]L:9M(4000x2248), M:5M(3072x1728), S:2M(1920x1080)\\r [1:1]L:9M(2992x2992), M:5M(2304x2304), 2M(1440x1440)\\r \\r RAW\\r [4:3]12M(4000x3000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax Q
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Contrast Detection Auto Focus
Auto Focus (AF) points selection	Auto, Manual
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Shutter speed settings	B
Camera shutter interval	3 s
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Slow synchronization
Flash guide number	4.9 m
Flash exposure correction	-2EV - +1EV (1/2 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	Eye-Fi, SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Yellow
Scene modes	Backlight, Candlelight, Children, Close-up (macro), Cuisine, Museum, Night, Night landscape, Night portrait, Pet, Portrait, Sunset, Twilight, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Muted, Neutral
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Shutter priority
Camera playback	Movie, Single image
Self-timer delay	2, 12 s
Languages support	CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3, RAW
Playback zoom (max)	16 x
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Battery type	D-LI68
Battery life (CIPA standard)	260 shots
Cables included	USB
Bundled software	SILKYPIX Developer Studio 3.0 LE

Weight and Dimensions

Depth	33.5 mm
Width	102 mm
Height	58 mm
Weight	180 g
Weight (including battery)	200 g
