or on a sensor line.
The menu EFLT Ratio shows the asymmetry of the AS-i network, referenced to
ground (see sketch).
9.5.4 Current can be read directly on the unit
Now the devices display both the maximum current and the current actually
present in the respective AS-i circuit. Heavy consumers or a strong overload in an
AS-i circuit are then easy to detect. Plus you can set the maximum current in the
AS-i circuit on these devices. This ensures line protection even when using large
24V power supplies.
1.
Earth fault sen.
EFLT Ratio: "
AS-i+ 2%
AS-i DC Voltage: 1
31,3V
$
EFLT Ratio: "
AS-i+ 100%
AS-i DC Voltage: 2
31,5V
AS-i +
AS-i -
0%
100%
%
%
100%
AS-i power
Reset
Maximal: 2
1,3A
!
