Pepperl+Fuchs AS-I 3.0 PROFIBUS User Manual

AS-i 3.0 PROFIBUS Gateway in Stainless Steel
PROFIBUS DP
26.9.2013
45
10.1.1.3 Parameters
With the user parameters you can choose if and which slave list will be displayed
in the diagnosis. Furthermore you can select which conditions have to be fulfilled
to set the ExtDiag bit within the diagnostic telegram.
……
12 delta (56 … 63)
LPF
Byte description
1 0x0C header
2 0xA4 (circuit 1)/0xA5 (circuit 2) type
3 0x00 slot
4 0x00 spec
5 LPF (0 ... 7)
6 LPF (8 ... 15)
……
12 LPF (56 … 63)
Tab. 10-7.
Delta list
Byte description
Tab. 10-6.
DP parameters - single master
PDU byte user byte DP DP/V1 user default
1 – Station_Status 4
2 – WD_Fact_1 4
3 – WD_Fact_2 4
4–min T
sdr
4
5 – Ident High 4
6 – Ident Low 4
7 – Group_Ident 4
8 1 DPV Status 1 4 80
16
9 2 DPV Status 2 4 00
16
10 3 DPV Status 3 4 00
16
Tab. 10-8.
