AS-i 3.0 PROFIBUS Gateway in Stainless Steel
PROFIBUS DP
The bits in "user byte 1" and "user byte 3" have the following meanings:
11 4 User Byte 1 4 0B
16
12 5 User Byte 2 4 06
16
13 6 User Byte 3 4 00
16
DP parameters - double master
PDU byte user byte DP DP/V1 user default
1 – Station_Status 4
2–WD_Fact_1 4
3–WD_Fact_2 4
4–min T
sdr
4
5 – ident high 4
6–ident low 4
7 – Group_Ident 4
8 1 DPV status 1 4 80
16
9 2 DPV status 2 4 00
16
10 3 DPV status 3 4 00
16
11 4 user byte 1, circuit 1 4 0B
16
12 5 user byte 2, circuit 1 4 06
16
13 6 user byte 3, circuit 1 4 00
16
14 7 user byte 1, circuit 2 4 0B
16
15 8 user byte 2, circuit 2 4 06
16
16 9 user byte 3, circuit 2 4 00
16
Tab. 10-9.
user byte 1
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
-
-
LPF – D F
default0 0 01011
Tab. 10-10.
DP parameters - single master
PDU byte user byte DP DP/V1 user default
Tab. 10-8.
