26.9.2013
70
AS-i 3.0 PROFIBUS Gateway in Stainless Steel
Appendix: Example for startup on a Siemens S7
In this example the data transfer of the 16 byte in-/output data of the VBG-PB-
K30-D-S takes place in (out) the CPU address range Input (output) data image
byte 0 to 15.
12.2.4 AS-i 3.0 PROFIBUS Gateway in Stainless Steel parameters
The VBG-PB-K30-D-S is symbolically represented as a rectangular window con-
nected with the PROFIBUS branch. Double-clicking in the upper line of this win-
dow [(3) P+F 15] opens the dialog window for the properties of this PROFIBUS
slave.
