AS-i 3.0 PROFIBUS Gateway in Stainless Steel
Electrical connection
7.1.2 VBG-PB-K20-D-EV1, VBG-PB-K20-DMD-EV1, VBG-PB-K20-D-EV
Legend:
[1] Ethernet diagnostics port
1
[2] LEDs
[3] D-sub connection (PROFIBUS interface)
[4] LC display
[5] Push-buttons
[6] AS-i and power supply terminal
[7] Chip card
1. Only in conjunction with AS-i Control Tools
+
-
+
-
+
-
[2]
[3]
[4]
[5]
[1]
[6]
[7]
10
10
AWG 24 ... 12
0,2 ... 2,5 mm
2
0,2 ... 2,5 mm
2
