AS-i 3.0 PROFIBUS Gateway in Stainless Steel
PROFIBUS DP
The conditions when to set the ExtDiag bit can be chosen using the user parame-
ters or the commands of the command interface.
The GSD file includes the following presettings:
The diagnosis transmitts ec-flags, delta list and LPF.
ExtDiag will be set if ConfigError = 1 and APF = 1. ExtDiag will not be set if
there is a periphery fault.
If a double master is being used, the data for AS-i circuit are transmitted in the
user parameter bytes 4 to 6. For circuit 2 3 additional bytes are added.
10.1.1.1 Diagnostic description for VBG-PB-K20-D-BV
DP diagnostics - single master
PDU byte user byte DP DP/V1 user
1 station_status 1 4
2 station_status 2 4
3 station_status 3 4
4 master address 4
5 ident high 4
6 ident low 4
7 1 header 4 4
82type 4
93slot 4
10 4 spec 4
11 5 ec-flags (high) 4
12 6 ec-flags (low) 4
13 7 delta (0…7) 4
14 8 delta (8…15) 4
……
20 14 delta (56…63) 4
21 15 LPF (0…7) 4
……
28 22 LPF (56 … 63) 4
Tab. 10-2.
