AS-i 3.0 PROFIBUS Gateway in Stainless Steel
Codes Indicated by the Display
26.9.2013
85
13. Codes Indicated by the Display
In the basic state of the configuration mode, the addresses of all detected slaves
are displayed in two-second intervals. A blank display indicates that the LDS (List
of Detected Slaves) is empty, no slaves were detected.
In the basic state of the protected operating mode, the display is either blank or
displays the address of a faulty assignment.
During manual address programming, the slave address display has a different
meaning (see also chapter "Operating in advanced display mode").
All displayed numbers bigger than 31 which can not be interpreted as a slave ad-
dress are status or error messages of the master. They have the following mean-
ings:
39 Advanced AS-i diagnostics: After pressing the ’set’-button a short-time AS-i
power failure occurred.
40 The AS-i master is in offline phase.
41 The AS-i master is in detection phase.
42 The AS-i master is in activation phase.
43 The AS-i master starts the normal operating mode.
68 Hardware error: disturbed internal communication.
69 Hardware error: disturbed internal communication.
70 Hardware error: The AS-i master’s EEPROM cannot be written.
71 Wrong PIC-type.
72 Hardware error: wrong PIC-processor.
73 Hardware error: wrong PIC-processor.
74 Checksum error in the EEPROM.
75 Error in the internal RAM.
76 Error in the external RAM.
77 AS-i control software error: Stack overflow (AS-i control II)
78 AS-i control software error: checksum error in the control program.
"control checksum":
checksumm in Control III C program (bin.file) not correct. The file is possibly
damaged.
"control exec err":
error in Control III C program.
"control watchdog":
watchdog predetermined in Control III C program has expired .
"control incomp":
Control III C program from another gateway type loaded (e.g. Ethernet IP in
Profibus gateway).
