AS-i 3.0 PROFIBUS Gateway in Stainless Steel
General
26.9.2013
9
4. General
4.1 Product information
This system manual applies to the following Pepperl+Fuchs GmbH equipment:
4.2 AS-i 3.0 PROFIBUS Gateway in Stainless Steel
The AS-i/PROFIBUS Gateways serve to connect AS-i systems to the superordi-
nate PROFIBUS. The gateways act as a master for AS-i and as a slave on
PROFIBUS.
The AS-i/PROFIBUS Gateways are designed to connect AS-i systems to an up-
per-level PROFIBUS network. The gateways act as a master for AS-i and as a
slave on PROFIBUS.
All AS-i functions can be used cyclically as well as acyclically via PROFIBUS
DP/ V1.
For the cyclical data transfer up to 32 bytes of I/O data can be transferred as bina-
ry data for one AS-i network. Additionally, analog signals and all available com-
mands of the new AS-i specification can be transferred via the command channel
through PROFIBUS.
On the serial PROFIBUS Master AS-i Control Tools can be used to monitor the
AS-i data online via PROFIBUS DP/V1.
Article no. Model Protection rating Fieldbus interface Number of AS-i networks, number of AS-i Master 1 power supply, 1 gateway for 2 AS-i networks, inexpensive power supplies Diagnostic and configuration interface Recognition of duplicate AS-i addresses AS-i fault detector AS-i Power24V
1
1. AS-i Power24V capable.
The devices can be operated directly on a 24V (PELV) power supply. The gateway VBG-PB-K20-
D-EV is optimized with integrated data coupling coils and adjustable self-resetting fuses for safe
use also of powerful 24V power supplies. The gateways VBG-PB-K20-D-EV1 and VBG-PB-K20-
DMD-EV1 need to add in Power24V-operation a power supply decoupling unit.
Programming in C
VBG-PB-K20-
D-EV
Gateway P20 PROFIBUS
2 AS-i net-
works, 2 AS-i
Masters
yes, max. 4A/
AS-i network
Ethernet yes yes yes
optio
nal
VBG-PB-K20-
DMD-EV1
Gateway IP20 PROFIBUS
2 AS-i net-
works, 2 AS-i
Masters
no, max. 8A/
AS-i network,
redundant
supply
Ethernet yes yes yes
optio
nal
VBG-PB-K20-
D-EV1
Gateway IP20 PROFIBUS
1 AS-i net-
work, 1 AS-i
Master
no, max. 8A/
AS-i network,
redundant
supply
Ethernet yes yes yes
optio
nal
VBG-PB-K20-
D-BV
Gateway IP20 PROFIBUS
1 AS-i net-
work, 1 AS-i
Master
no, max. 8A/
AS-i network
—noyesnono
Tab. 4-1.
