Peri RCS P - Closing Gaps; Components

41
43
45
99
C4 Suspension on the Structure
Closing Gaps
Components
41 Foldable Cover (multi-layer
plywood sheeting)
43 Cover RCS 70 x 70
45 Slab Shoe RCS
1. Cover all gaps in the area of the Slab
Shoe with Cover RCS 70x70 (43).
(Fig. C4.07)
2. If necessary, nail the Cover on the
Foldable Cover.
Cover any remaining gaps with suitable
means, e.g. Elastomer cover strips.
Make sure that neither the climbing
procedure nor the opening of the flaps
is impaired in any way.
Fig. C4.07
RCS P Climbing Protection Panel
Instructions for Assembly and Use – Standard Configuration
