Operation Section
Lifting and Storage
i09996861
Product Lifting
Engine Only
NOTICE
Always inspect lifting eyebolts and all other lifting
equipment for damage before performing any lifting.
Never bend the eyebolts and the brackets. Never
perform product lifting if components are damaged.
Only load the eyebolts and the brackets under ten-
sion. Remember that the capacity of an eyebolt is
less as the angle between the supporting members
and the object becomes less than 90 degrees.
Use a hoist to remove heavy components. Use a
lifting beam to lift the engine. All supporting members
(chains and cables) should be parallel to each other.
The chains and cables should be perpendicular to
the top of the object that is being lifted.
To remove the engine, use the lifting eyes that are on
the engine. If necessary, remove engine components
to avoid damage from the lifting device.
Lifting eyes are designed and installed for specific
engine arrangements. Alterations to the lifting eyes
and/or the engine make the lifting eyes and the lifting
fixtures obsolete. If alterations are made, ensure that
correct lifting devices are provided. Consult your
Perkins distributor for information regarding fixtures
for correct engine lifting.
The radiator and the engine are to be disassembled
before lifting and to be lifted separately.
M0163009 29
Operation Section
Lifting and Storage
