Warning Labels Position Bank B
Illustration 2 g07671804
Typical example
(1) Universal warning label locations
(2) Do not step label location
(3) Electrocution danger label location
(4) Hot surface label location
(5) Hot fluid under pressure label locations
(not shown)
(6) Ether warning label location
Universal Warning
Illustration 3 g06019365
Universal Warning label
Do not operate or work on this equipment unless
you have read and understand the instructions
and warnings in the Operation and Maintenance
Manuals. Failure to follow the instructions or
heed the warnings could result in serious injury
or death.
The universal warning label (1) is installed on the
valve mechanism cover of cylinder 1 and cylinder 6.
Do Not Step
Do not step safety message (2) can be found on the
engine oil cooler and the heat shield of the coolant
rail.
8 M0163009
Safety Section
Safety Messages
