Drain
Pressurized System: Hot coolant can cause seri-
ous burns. To open the cooling system filler cap,
stop the engine and wait until the cooling system
components are cool. Loosen the cooling system
pressure cap slowly in order to relieve the
pressure.
Illustration 51 g07693467
Typical example
Illustration 52 g06258129
Typical example
1. Stop the engine and allow the engine to cool.
Isolate the electrical supply to the engine. Loosen
the cooling system filler cap (1) slowly to relieve
any pressure. Remove the cooling system filler
cap.
2. Clean the cooling system filler cap (1) and inspect
the seal (2). If the seal is damaged, discard the old
filler cap and install a new filler cap. If the seal is
not damaged, use a suitable pressurizing pump to
pressure test the filler cap. The correct pressure is
stamped on the face of the filler cap. If the filler
cap does not retain the correct pressure, replace
the filler cap.
3. Remove the drain plug (3) on the radiator.
Illustration 53 g07693484
Typical example of Bank A
Illustration 54 g07693475
Typical example of Bank B
66 M0163009
Maintenance Section
Cooling System Coolant (ELC) - Change
