TPD1317e Chapter 11
Page 67
Reference Data
11.1 M300Ti and M265Ti Engines
Model M300Ti Model M265Ti
Basic Technical Data
Rated power 286 ps (210.4 kW) 253.4 ps (186.2 kW)
Rated engine speed 2500 rpm
Number of cylinders 6
Cylinder arrangement In-line
Cycle 4 Stroke
Induction System Wastegated turbocharger with charge air cooling
Bore 100 mm (3.937”)
Stroke 127mm (5.00”)
Compression Ratio 17.5:1
Cubic Capacity 5.995 Litre (365 in
3
)
Valves per cylinder 2
Direction of Rotation Anti-clockwise viewed from ywheel
Firing Order 1, 5, 3, 6, 2, 4
Total Weight (wet) 635 kg (1400 lbs) engine only including alternator and starter.
718 kg (1583 lbs) engine with ZF IRM 220A gearbox
Cooling System The coolant shown is mandatory for use in all climates to
ensure that adequate levels of corrosion inhibitor are present.
It will give frost protection to -37
o
C.
Coolant 50% inhibited ethylene glycol or
50% inhibited propylene glycol with 50% fresh clean water.
Fresh Water Flow 205 litre/min at 2500 rpm
Coolant pump speed and
method of drive 1:1 Gear Driven
System Capacity 26.3 litres (5.6 gallons)
Pressure cap setting 50 kPa (7 psi)
Protection switch setting 96
o
C
Sea water pump type Jabsco gear driven model 080 full cam
Sea water suggested inlet 32 mm Bore (1.25”)
hose diameter
