OPTIONAL GAUGES
Suspension Load
Air Tractor Brake Application Trailer Brake Application Air
Pressure, #1, #2 Air Pressure Pressure
Suspension Load Air Pressure #1
Suspension Load Air Pressure #2
The Suspension
Load Air Pressure
gauge indicates the amount of air
pressure in the air suspension air bags.
When the
vehicle is equipped with dual
leveling valves, the #1 gauge indicates
the air pressure in the driver's side air
bags. The #2 gauge indicates the air
pressure in the passenger's side air
bags.
The Tractor
Brake Application Air
The Trailer
Brake Application Air
Pressure gauge
indicates the amount
Pressure gauge
indicates the amount
of air
pressure applied to the tractor
of air
pressure applied to the trailer
brakes.
brakes during
brake foot valve and/or
hand brake control valve applications.
