HEATER AND AIR CONDITIONER
the side of the lter element with Cab Recirculation Air Filter
the airow direction that is clearly
marked on the air intake housing.
Please contact an authorized dealer
when the service interval is required to
inspect the cabin recirculation air lter.
6. Replace the
lter cover on the air
intake housing and slide the cover
forward in vehicle. An audible
snap sound can be heard when
the cover is correctly in place. If
the snap feature is damaged there
are two screw features that may
be utilized to retain the cover in
place.
7. Close and
secure hood of vehicle.
(04/13) Y53-6047–2C
Sleeper HVAC Air Filter
The sleeper
recirculation lter is
located under the sleeper bunk on the
passenger side of the vehicle. Lift the
bottom bunk to access the unit. The
lter can be replaced without using
any tools.
1. Lift
the sleeper bunk to expose the
sleeper HVAC module.
2. Find the retention tab at the side
of the lter element and move it to
release the lter. Moving this tab
5-113
