NOISE AND EMISSION CONTROL
The exhaust piping can become ex-
tremely hot during engine operation
and can cause personal injury includ
-
ing serious burns to the skin. Allow
adequate cooling time before working
near any part of the exhaust system.
WARNING!
2. Remove the pump protective plate
mounted on the bottom of the DEF
tank.
Exhaust Tail Pipe
3. Using a
27 mm socket wrench
(DIN3124), remove the lter cap
• Check the mounting. Tighten as
that is screwed to the DEF Supply
necessary. The miter cut at the tip
pump.
of the pipe must be facing the rear
of the
vehicle. Do not modify the
end of the pipe in any way.
5
(04/13) Y53-6047–2C 5-121
