SERVICE OPERATIONS
26
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
Replacing the clutch lining assembly
- Compress the clutch drive pulley and driven
pulley assembly with the tool P/N 752127
clamped in the jaws of a vice.
- Remove nut (1) using spanner P/N 752361.
Tightening torque: 55 Nm.
- Slacken tool P/N 752127.
- Remove the clutch lining assembly (2).
- When re-installing the driven pulley,
lubricate the needle bearing (3).
752361
1
752127
3
2
