Adjustment
13 - 43
600 604 Last engaging and disengaging
positions for end knotting
605 Needle penetration point in fabric 0 - 127 43
606 Set reference offset clamp (X) and (0) (0)
needle (Y) (correction values for the
stepping motors zero points)
607 Turn sewing motor in sewing direction
608 Carry out cold start
610 Needle penetration points for
adjustment
1: Centre
2: Max. penetration point right
3: Max. penetration point left
4: Button gauge: centre
5: Button gauge: front left
6: Button gauge: back left
7: Button gauge: back right
8: Button gauge: front right
611 Suppression thread trimming I, II I
(I = OFF, II = ON)
612 Adjusting aid for zero position of stepping 0
motor using synchronisation mark
614 Set cutting position X on right ± 25 5
615 Set cutting position X on left ± 25 8
700 701 P-quota speed controller 1 - 50 10
702 I-quota speed controller 0 - 100 50
703 P-quota position controller 1 - 50 20
704 D-quota position controller 1 - 100 30
705 Time for position controller 1 - 100 25
706 P-quota position controller for rest brake 1 - 50 25
707 D-quota position controller for rest brake 1 - 50 15
708 Maximum moment for rest brake 0 - 100 0
709 Minimum machine speed 3 - 64 6
710 Maximum machine speed 100 - 2000 2000
711 Maximum motor speed 0 100 45
712 Positioning speed 3 - 35 25
Group Parameter Description Setting Set value
range
