Pfaff 3307-1 SERIES User Manual

Adjustment
13 - 42
600 601 Move stepping motor
clamp and needle
602 Display inputs
0123456789ABCDEF
0I
Position on the Display
0: Not assigned - -
1: Not assigned - -
2: Needle in material (NIS) - -
3: End knotting engaged off
▲
on
(E16 - X5:7)
4: Error reset key S101 (E12 – X5:12) off
▲
on
5: Not assigned (E11 - X5:11) - -
6: Not assigned (E10 - X5:10) - -
7: Not assigned (E9 - X5:9) - -
8: Programmable input 1 - -
(E8 - X5:16)
9: Programmable input 2 - -
(E7 - X5:15)
A: Not assigned (E6 - X5:14) - -
B: Not assigned (E5 - X5:5) - -
C: Clamp lowered (E4 - X5:3 raised
▲
lowered
D: Not assigned (E3 - X5:3) - -
E: Reference needle (photoelectric barrier) switched not assigned
F: Reference clamp (photoelectric barrier) switched not assigned
603 Switch outputs
Position on the Display Meaning of the display value
0I
1: Clamp (X13:1) lowered raised
▲
2: Not assigned (X13:3) - -
3: Thread clamp (X13:5) open closed
▲
4: Thread trimming (X13:6) off
▲
on
5: End knotting (X13:7) off
▲
on
6: Thread puller (X13:8) off
▲
on
7: Thread wiper (X13:9) off
▲
on
8: Not assigned (X13:10) - -
9: Not assigned (X13:11) - -
10:Not assigned (X13:12) - -
11:Not assigned (X13:13) - -
12:Not assigned (X13:25) - -
13:Not assigned (X13:24) - -
14:Self-shank button holder (X13:16) off
▲
on
15:Not assigned (X13:17) - -
16:Missed stitch lamp (X5:24) off
▲
on
Group Parameter Description Setting Set value
range
▲
= basic position
Meaning of the display value
