Protective cover for the fore-vacuum connection
●
Mating plug for the "remote" connection on the TC 1200 (type-dependent)
●
Mating plug for the "E74" connection on the TC 1200 (type-dependent)
●
Mains power socket HAN 3A for mains connection of the turbopump
●
Sealing gas valve (enclosed)
●
Operating fluid F3 (50 ml) with syringe
●
2 eye bolts for transport
●
2 threaded hose nozzles with sealing ring for cooling water connection, G 1/4"
●
Operating instructions
3.3 Identifying the product
►
To ensure clear identification of the product when communicating with Pfeiffer Vacuum, always
keep all of the information on the rating plate to hand.
►
Learn about certifications through test seals on the product or at www.certipedia.com with compa-
ny ID no. 000021320.
3.3.1 Product types
The product designation of Pfeiffer Vacuum turbopumps from the HiPace series is composed of the
family name, the size (which is based on the pumping speed of the vacuum pump) and, if required, an
additional feature description.
Family Size/model Property, attribute, feature
HiPace 10 to 2800 none = Standard version
mini = Compact version
U = Overhead version
C = Corrosive gas version
P = Process
M = Active magnetic bearing
T = Temperature management
Plus = Low vibration, low magnetic field
E = High efficiency
H = High compression
I = Ion implantation
Tbl. 4: Product designation of Pfeiffer Vacuum HiPace turbopumps
3.3.2 Product features
Feature Version
HV flange DN 200 ISO-K DN 200 ISO-F DN 200 CF-F
Flange material Aluminium Aluminium Stainless steel
Tbl. 5: Turbopump features
Mains voltage ± 10% Motor input power of the electronic drive unit
100 to 120 V AC 700 to 930 W
200 to 240 V AC 1200 W
Tbl. 6: Delivered drive power depending on the supplied mains voltage
Product description
21/74
