Procedure
1. With rigid pipe connections, include bellows to attenuate external vibrations.
2. Install a fore-vacuum connection with small flange components, e.g. connection elements and
pipe components DN 40 ISO-KF from the Pfeiffer Vacuum Components Shop.
3. Implement measures to counteract the backflow of operating fluids or condensate from the fore-
vacuum area.
4. Observe the information in the operating instructions of the backup pump or pumping station when
connecting and operating it.
5.5 Connecting the cooling water supply
WARNING
Risk of scalding from suddenly escaping hot cooling water
The turbopump water connections are open to both sides. When connecting the cooling water supply,
there is a risk of scalding from suddenly escaping, hot cooling water at over pressure.
►
Prior to installation, ensure that pressure is discharged from the cooling water system, and that it
is cooled down.
►
Wear protective equipment, e.g., safety goggles and gloves.
Parameter Cooling water
Appearance ● filtered
● mechanically clear
● visually clear
● no turbidity
● no sediment
● free from grease and oil
pH value 7 to 9
Carbonate hardness, max. 10 °dH
12.53 °e
17.8 °fH
178 ppm CaC0
3
Chloride content, max. 100 mg/l
Sulfate content, max. 240 mg/l
Carbonic acid content, max. not detectable
Ammonia content, max. not detectable
Electrical conductivity, max. 500 µS/cm
Particle size, max. 150 µm
Cooling water temperature see "Technical data"
Cooling water flow see "Technical data"
Feed line overpressure, max. 6000 hPa
Tbl. 9: Requirements on the cooling water composition
The HiPace 1200 turbopumps use water cooling as standard.
Connection to the turbopump External cooling water supply
Internal thread, G 1/4" Hose cable
Hose nozzles (included with shipment) Inner hose diameter 7 to 8 mm
Tbl. 10: Requirements on the cooling water connection
Installation
36/74
