14 Technical data and dimensions
14.1 General
This section describes the basis for the technical data of Pfeiffer Vacuum turbopumps.
Technical data
Maximum values refer exclusively to the input as a single load.
●
Specifications according to PNEUROP committee PN5
●
ISO 27892 2010:"Vacuum technology - Turbomolecular pumps - Measurement of rapid shutdown
torque"
●
ISO 21360 2012: “Vacuum technology - Standard methods for measuring vacuum-pump perform-
ance - Part 1: General description”
●
ISO 21360 2018: "Vacuum technology - Standard methods for measuring vacuum-pump perform-
ance - Part 4: Turbomolecular vacuum pumps"
●
Ultimate pressure with test dome after 48 h bake out duration
●
Gas throughput with water cooling; backing pump = rotary vane pump (10 m
3
/h)
●
Cooling water consumption at maximum gas throughput, cooling water temperature 25 °C
●
Integral leakage rate with 100 % helium concentration, 10 s measurement duration
●
Sound pressure level at distance to vacuum pump = 1 m
mbar bar Pa hPa kPa Torr | mm Hg
mbar 1
1 · 10
-3
100 1 0.1 0.75
bar 1000 1
1 · 10
5
1000 100 750
Pa 0.01
1 · 10
-5
1 0.01
1 · 10
-3
7.5 · 10
-3
hPa 1
1 · 10
-3
100 1 0.1 0.75
kPa 10 0.01 1000 10 1 7.5
Torr | mm Hg 1.33
1.33 · 10
-3
133.32 1.33 0.133 1
1 Pa = 1 N/m
2
Tbl. 20: Conversion table: Pressure units
mbar l/s
Pa m
3
/s
sccm Torr l/s
atm cm
3
/s
mbar l/s 1 0.1 59.2 0.75 0.987
Pa m
3
/s
10 1 592 7.5 9.87
sccm
1.69 · 10
-2
1.69 · 10
-3
1
1.27 · 10
-2
1.67 · 10
-2
Torr l/s 1.33 0.133 78.9 1 1.32
atm cm
3
/s
1.01 0.101 59.8 0.76 1
Tbl. 21: Conversion table: Units for gas throughput
14.2 Technical data
Selection field HiPace® 1200 with
TC 1200, DN 200
ISO-K
HiPace® 1200 with
TC 1200, DN 200
ISO-F
HiPace® 1200 with
TC 1200, DN 200
CF-F
Part number PM P06 000 PM P06 001 PM P06 002
Connection flange (in) DN 200 ISO-K DN 200 ISO-F DN 200 CF-F
Connection flange (out) DN 40 ISO-KF DN 40 ISO-KF DN 40 ISO-KF
Final pressure without gas bal-
last
1 · 10
-7
hPa 1 · 10
-7
hPa 5 · 10
-10
hPa
Pumping speed for Ar 1200 l/s 1200 l/s 1200 l/s
Pumping speed for H
2
1100 l/s 1100 l/s 1100 l/s
Technical data and dimensions
