Pfeiffer Vacuum PMP06021 - Page 65

Selection field HiPace® 1200 with
TC 1200, DN 200
ISO-K
HiPace® 1200 with
TC 1200, DN 200
ISO-F
HiPace® 1200 with
TC 1200, DN 200
CF-F
Pumping speed for He 1300 l/s 1300 l/s 1300 l/s
Pumping speed for N
2
1250 l/s 1250 l/s 1250 l/s
Gas throughput at final rotation
speed for Ar
11 hPa·l/s 11 hPa·l/s 6 hPa·l/s
Gas throughput at final rotation
speed for H
2
> 30 hPa·l/s > 30 hPa·l/s > 30 hPa·l/s
Gas throughput at final rotation
speed for He
> 30 hPa·l/s > 30 hPa·l/s 16 hPa·l/s
Gas throughput at final rotation
speed for N
2
20 hPa·l/s 20 hPa·l/s 16 hPa·l/s
Fore-vacuum max. for N
2
2 hPa 2 hPa 2 hPa
Fore-vacuum max. for Ar 2.5 hPa 2.5 hPa 2.5 hPa
Fore-vacuum max. for H
2
0.25 hPa 0.25 hPa 0.25 hPa
Fore-vacuum max. for He 0.9 hPa 0.9 hPa 0.9 hPa
Compression ratio for Ar
1 · 10
8
1 · 10
8
1 · 10
8
Compression ratio for H
2
6 · 10
3
6 · 10
3
6 · 10
3
Compression ratio for He
2 · 10
4
2 · 10
4
2 · 10
4
Compression ratio for N
2
1 · 10
8
1 · 10
8
1 · 10
8
Performance curve in gas
mode 0, vertex C
474/37800 W/min
-1
474/37800 W/min
-1
474/37800 W/min
-1
Performance curve in gas
mode 0, vertex D
650/30240 W/min
-1
650/30240 W/min
-1
650/30240 W/min
-1
Performance curve in gas
mode 1, vertex A
712/37800 W/min
-1
712/37800 W/min
-1
712/37800 W/min
-1
Performance curve in gas
mode 1, vertex B
750/30240 W/min
-1
750/30240 W/min
-1
750/30240 W/min
-1
Rotation speed ± 2 % 37800 rpm 37800 rpm 37800 rpm
Rotation speed variable 50 – 100 % 50 – 100 % 50 – 100 %
Run-up time 2.5 min 2.5 min 2.5 min
Sound pressure level 50 dB(A) 50 dB(A) 50 dB(A)
Integral leakage rate
1 · 10
-8
Pa m³/s 1 · 10
-8
Pa m³/s 1 · 10
-8
Pa m³/s
Venting connection G 1/8" G 1/8" G 1/8"
Max. connection pressure
(abs.) for venting/sealing gas
valve
1500 hPa 1500 hPa 1500 hPa
Electronic drive unit TC 1200 TC 1200 TC 1200
Mains connection: voltage
(range)
100 – 120/200 – 240
V AC
100 – 120/200 – 240
V AC
100 – 120/200 –
240 V AC
Mains connection: frequency
(range)
50/60 Hz 50/60 Hz 50/60 Hz
Power consumption max. 1350 VA 1350 VA 1350 VA
Current, max. 10 A 10 A 10 A
Cooling water connection G 1/4” G 1/4” G 1/4”
Cooling method, standard Water Water Water
Cooling water temperature 15 – 35 °C 15 – 35 °C 15 – 35 °C
Cooling water flow 100 l/h 100 l/h 100 l/h
Permissible radial magnetic
field max.
6 mT 6 mT 6 mT
Protection degree IP54 IP54 IP54
Relative humidity of air 5 – 85 %, non-con-
densing
5 – 85 %, non-con-
densing
5 – 85 %, non-con-
densing
Technical data and dimensions
