Selection field HiPace® 1200 with
TC 1200, DN 200
ISO-K
HiPace® 1200 with
TC 1200, DN 200
ISO-F
HiPace® 1200 with
TC 1200, DN 200
CF-F
Mounting orientation 0° (HV flange top) –
90°
0° (HV flange top) –
90°
0° (HV flange top) –
90°
Weight 29.5 kg 30.5 kg 40.9 kg
Tbl. 22: Technical data for HiPace 1200 Standard
Selection field HiPace® 1200 U
with TC 1200, DN
200 ISO-K
HiPace® 1200 U
with TC 1200, DN
200 ISO-F
HiPace® 1200 U
with TC 1200, DN
200 CF-F
Part number PM P06 010 PM P06 011 PM P06 012
Connection flange (in) DN 200 ISO-K DN 200 ISO-F DN 200 CF-F
Connection flange (out) DN 40 ISO-KF DN 40 ISO-KF DN 40 ISO-KF
Final pressure without gas bal-
last
1 · 10
-7
hPa 1 · 10
-7
hPa 5 · 10
-10
hPa
Pumping speed for Ar 1200 l/s 1200 l/s 1200 l/s
Pumping speed for H
2
1100 l/s 1100 l/s 1100 l/s
Pumping speed for He 1300 l/s 1300 l/s 1300 l/s
Pumping speed for N
2
1250 l/s 1250 l/s 1250 l/s
Gas throughput at final rotation
speed for Ar
11 hPa·l/s 11 hPa·l/s 6 hPa·l/s
Gas throughput at final rotation
speed for H
2
> 30 hPa·l/s > 30 hPa·l/s > 30 hPa·l/s
Gas throughput at final rotation
speed for He
> 30 hPa·l/s > 30 hPa·l/s 16 hPa·l/s
Gas throughput at final rotation
speed for N
2
20 hPa·l/s 20 hPa·l/s 16 hPa·l/s
Fore-vacuum max. for N
2
2 hPa 2 hPa 2 hPa
Fore-vacuum max. for Ar 2.5 hPa 2.5 hPa 2.5 hPa
Fore-vacuum max. for H
2
0.25 hPa 0.25 hPa 0.25 hPa
Fore-vacuum max. for He 0.9 hPa 0.9 hPa 0.9 hPa
Compression ratio for Ar
1 · 10
8
1 · 10
8
1 · 10
8
Compression ratio for H
2
6 · 10
3
6 · 10
3
6 · 10
3
Compression ratio for He
2 · 10
4
2 · 10
4
2 · 10
4
Compression ratio for N
2
1 · 10
8
1 · 10
8
1 · 10
8
Performance curve in gas
mode 0, vertex C
474/37800 W/min
-1
474/37800 W/min
-1
474/37800 W/min
-1
Performance curve in gas
mode 0, vertex D
650/30240 W/min
-1
650/30240 W/min
-1
650/30240 W/min
-1
Performance curve in gas
mode 1, vertex A
712/37800 W/min
-1
712/37800 W/min
-1
712/37800 W/min
-1
Performance curve in gas
mode 1, vertex B
750/30240 W/min
-1
750/30240 W/min
-1
750/30240 W/min
-1
Rotation speed ± 2 % 37800 rpm 37800 rpm 37800 rpm
Rotation speed variable 50 – 100 % 50 – 100 % 50 – 100 %
Run-up time 2.5 min 2.5 min 2.5 min
Sound pressure level 50 dB(A) 50 dB(A) 50 dB(A)
Integral leakage rate
1 · 10
-8
Pa m³/s 1 · 10
-8
Pa m³/s 1 · 10
-8
Pa m³/s
Venting connection G 1/8" G 1/8" G 1/8"
Max. connection pressure
(abs.) for venting/sealing gas
valve
1500 hPa 1500 hPa 1500 hPa
Electronic drive unit TC 1200 TC 1200 TC 1200
Technical data and dimensions
66/74
