Selection field HiPace® 1200 C
with TC 1200, DN
200 ISO-K, corro-
sive
HiPace® 1200 C
with TC 1200, DN
200 ISO-F, corro-
sive
HiPace® 1200 C
with TC 1200, DN
200 CF-F, corro-
sive
Performance curve in gas
mode 0, vertex D
650/30240 W/min
-1
650/30240 W/min
-1
650/30240 W/min
-1
Performance curve in gas
mode 1, vertex A
712/37800 W/min
-1
712/37800 W/min
-1
712/37800 W/min
-1
Performance curve in gas
mode 1, vertex B
750/30240 W/min
-1
750/30240 W/min
-1
750/30240 W/min
-1
Rotation speed ± 2 % 37800 rpm 37800 rpm 37800 rpm
Rotation speed variable 50 – 100 % 50 – 100 % 50 – 100 %
Run-up time 2.5 min 2.5 min 2.5 min
Sound pressure level 50 dB(A) 50 dB(A) 50 dB(A)
Integral leakage rate
1 · 10
-8
Pa m³/s 1 · 10
-8
Pa m³/s 1 · 10
-8
Pa m³/s
Venting connection G 1/8" G 1/8" G 1/8"
Max. connection pressure
(abs.) for venting/sealing gas
valve
1500 hPa 1500 hPa 1500 hPa
Electronic drive unit TC 1200 TC 1200 TC 1200
Mains connection: voltage
(range)
100 – 120/200 – 240
V AC
100 – 120/200 – 240
V AC
100 – 120/200 –
240 V AC
Mains connection: frequency
(range)
50/60 Hz 50/60 Hz 50/60 Hz
Power consumption max. 1350 VA 1350 VA 1350 VA
Current, max. 10 A 10 A 10 A
Cooling water connection G 1/4” G 1/4” G 1/4”
Cooling method, standard Water Water Water
Cooling water temperature 15 – 35 °C 15 – 35 °C 15 – 35 °C
Cooling water flow 100 l/h 100 l/h 100 l/h
Permissible radial magnetic
field max.
6 mT 6 mT 6 mT
Protection degree IP54 IP54 IP54
Relative humidity of air 5 – 85 %, non-con-
densing
5 – 85 %, non-con-
densing
5 – 85 %, non-con-
densing
Mounting orientation 0° (HV flange top) –
90°
0° (HV flange top) –
90°
0° (HV flange top) –
90°
Weight 30 kg 30.5 kg 40.9 kg
Tbl. 24: Technical data for HiPace 1200 C
Selection field HiPace® 1200 UC
with TC 1200, DN
200 ISO-K, corro-
sive
HiPace® 1200 UC
with TC 1200, DN
200 ISO-F, corro-
sive
HiPace® 1200 UC
with TC 1200, DN
200 CF-F, corro-
sive
Part number PM P06 030 PM P06 031 PM P06 032
Connection flange (in) DN 200 ISO-K DN 200 ISO-F DN 200 CF-F
Connection flange (out) DN 40 ISO-KF DN 40 ISO-KF DN 40 ISO-KF
Final pressure without gas
ballast
1 · 10
-7
hPa 1 · 10
-7
hPa 5 · 10
-10
hPa
Pumping speed for Ar 1200 l/s 1200 l/s 1200 l/s
Pumping speed for H
2
1100 l/s 1100 l/s 1100 l/s
Pumping speed for He 1300 l/s 1300 l/s 1300 l/s
Pumping speed for N
2
1250 l/s 1250 l/s 1250 l/s
Gas throughput at final rota-
tion speed for Ar
11 hPa·l/s 11 hPa·l/s 6 hPa·l/s
Technical data and dimensions
68/74
