A.Troubleshooting:
a.Engine starts, but vehicle don’t move.
1.driving belt worn out
2.driving plate worn out
3.clutch lining worn out
4.driving plate’s spring broken
b.the vehicle stops or tremble when running.
1.clutch lining spring cracked or broken.
c.Can’t reach high speed, no pick-up
1.driving belt worn out.
2.Driving plate spring distortion.
3.Weight roller worn out
4.Driving plate dirty.
Note:
No grease and oil should be distributed over
driving belt and driving plate.
B. Measurement data
Item
Standard value ( mm ) Limit of use
( mm )
The inner dia. Of slide driving
plate
24.011~24.052
24.10
The outer dia. Of boss, movable
Driving plate
23.960.~23.974 23.940
Belt width
20.0~21.0
19.0
Clutch lining thickness
3
1.5
Clutch outer inner diameter 125.0~125.2
125.5
Driven plate spring, free length 151
127
The outer diameter of driven
Plate sets
33.965~34.025 33.95
The inner diameter of slide
Driven plate
34.000~34.025 34.06
The outer diameter of weight
Roller set
17.920~18.080 17.40
