NO Locking location Q’ty
Thread dia.
(mm)
Locking torque
(kg-m)
1 Fixing nut (Tappet screw nut) 2 5 0.7~0.8
2 Nut of oil pump sprocket 1 6 0.7~1.0
3 Cylinder head bolt A (intake) 2 6 0.9~1.1
4 Guiding pin bolt, chain extensioner 1 6 0.4~0.6
5 Screw, chain extensioner 2 6 0.9~1.1
6 Cylinder head bolt B (Exhaust) 2 8 2.0~2.3
7 Flange nut, cam shaft holder 4 8 2.0~2.3
8 Gear oil drain bolt 1 8 1.7~2.0
9 Spark plug 1 10 1.2~1.3
10 Nut of fly wheel 1 12 5.0~6.0
11 Fixing nut, clutch outer 1 12 5.0~6.0
12 Nut, driving plate 1 12 5.0~6.0
13 Bolt of engine oil drain 1 12 2.5~3.0
14 Bolt of 2
nd
oil filter 1 12 0.8
15 Nut (LH thread), one-way clutch 1 22 9.0~10.0
16 Cap, coarse oil filter 1 30 1.5~2.0
2.
4T Engine (125/150/200/220CC)
