PGO G-MAX200 - G-MAX 200;220 Electric System; Headlamp & Choke (Carburetor) Diagram

5
G-MAX 200/220 Electric system
To headlamp & choke
RPM
1000
OFF
ON
Control timing
relay
Headlamp
switch
12V from
battery
Digital
controller
Green/
black
fuse
Headlamp & choke (carburetor) diagram
zWhen engine speed > 1000rpm,the digital controller permits the relay to
conduct the circuit
