6.2 Engine inspection data
CVT parts
Camshaft & valves
名 稱 Standard(mm) Using limit(mm)
Clearance between adjuster tapped
Screw and valve stem
(Before warm up)
IN & EX 0.08
Compression pressure(throttle open
full)
13kg/650rpm
IN 26.625 26.23
Height of the cam’s convex part
EX 26.530 26.13
Inner diameter of rocker arm shaft
IN & EX 10.000~10.015 10.10
Outer diameter of rocker arm shaft
IN & EX 9.972~9.987 9.91
IN 1.0 1.8
Valve base angle
EX 1.0 1.8
IN 4.975~4.990 4.900
Outer diameter of valve stem
EX 4.955~4.970 4.900
IN 5.000~5.012 5.30
Inner diameter of valve guide
EX 5.000~5.012 5.30
IN 0.010~0.037 0.08
Clearance between valve stem and
Valve guide
EX 0.030~0.057 0.10
The inner dia. Of slide drivingplat
27.011~27.021 27.10
The outer dia. Of boss,
movable Driving
26.970~26.990 26.95
Belt width 18
.7~19.3 17.70
Clutch lining thickness
31.50
Clutch outer inner diameter
130.0~130.2 130.50
Driven plate spring, free length
160 145.00
outer diameter of drivenPlate sets
33.965~33.985 33.95
inner diameter of slideDriven plat
To Next Page
