AUTO-ENRICHENER INSPECTION
y Disconnect the lead wire couplerc.
y Remove the coverd.
y Connect the positive ♁ terminal of a 12V battery to
Yellow/white lead and the negative Θ terminal to Black/
White.
y Check that the auto-enrichener section e (PTC heater
built-in area)is heated in 5 minutes after the battery has
been connected.
NOTE:
To inspect the function, check for change of temperature
from the cold condition.
!CAUTION
FLOAT HEIGHT ADJUSTMENT
To check the float height, turn the carburetor upside down.
Measure the float height A while the float arm is just con-
tacting the needle valve using vernier calipers.
Bend the tongue as necessary to bring the float height A
To the specified level.
Float height A: 20.8 ± 1.0mm
Do not attempt to disassemble the auto-enrichener
for the
