6.4 General maintenance

G-MAX 200/220 G-MAX125/150

Engine oil

Replace 1000cc

Total 1400cc

Replace 800cc

Total 1000cc

Gear oil

Replace 110cc

Total 130cc

Replace 90cc

Total 110cc

Oil filter 2

filter 2

filter

Air element Wet paper(bigger) Wet paper

CVT sponge Circle shape Oval shape

headlamp H4 55W/60W HS1 35W/35W
