PGO G-MAX200 - Locking Torque Value

(2) Locking Torque Value:
1. 2T Engine (50CC)
No
Locking location
Thread
Dia (mm)
Locking
torque kg-m
Remarks
1 Cylinder head 7 1.0~1.4 When the engine is
cold
2 Flywheel outer 10 3.2~4.0
3 Rear brake lever 6 1.0~1.2
4 Driving pulley 10 3.2~4.0
5 Clutch outer 10 3.5~4.0
6 Right crankcase 6 1.0~1.2
7 Drive gear box cover 6 1.0~1.2
8 Left crankcase 6 1.0~1.2
9 Draining and filler bolt 8 1.8 When the engine is
cold
10 Inlet pipe 6 1.0~1.2
11 Flywheel magneto stator 6 1.0~1.2
12 Cooling fan 6 1.0~1.2
13 Muffler nut on c
y
linder
head
6 1.0~1.2 When the engine is
cold
14 Starting motor 6 1.0~1.4 When the engine is
cold
15 Bracket between eng. and
Rubber pad of central stand
6 1.0~1.2
16 Spark plug 14 2.5~3.0
17 Fan cover 6 1.0~1.2
18 Fixed plate, drive clutch 6 1.0~1.4
19 Nut of rear wheel axle 14 11~13 U TYPE NUT
20 Kick starter 6 1.0~1.2
