PGO G-MAX200 - Chassis; Other Parts Standard Torque Values

NO Locking location Q’TY
Thread dia.
(mm)
Locking torque
(kg-m)
1 Air bleed bolt of caliper 1 6 0.6
2 Brake arm bolt, front drum 1 6 0.8~1.0
3 Brake arm bolt , rear drum 1 6 0.8~1.0
4 Nut of starter relay 2 6 0.5~0.6
5 Front brake caliper bolt 2 8 2.0 ~ 3.0
6 Bolt of disk 3 8 2.5~3.0
7 Locking nut, steering stem 1 10 3.5~4.5
8 Rear shock absorber bolt(lower) 1 10 3.5 ~ 4.5
9 Rear shock absorber bolt(upper) 1 10 3.5~4.5
10 Chassis bolt, engine hanger bracket 2 10 4.5 ~ 5.0
11 Engine bolt, engine hanger bracket 1 10 3.0 ~ 4.0
12 Hose bolt, master cyl. & caliper 2 10 2.5 ~ 3.0
13 Front axle nut 1 12 4.5 ~ 5.5
14 Nut, swing arm & connecting rod 1 14 4.5 ~ 5.5
14 Rear axle nut 1 16 10.0~11.0
3. Chassis
4. Other parts standard torque values:
No Item Torque
kg-m
1 5mm bolt and nut 0.45-0.6
2 6mm bolt and nut 0.8-1.2
3 8mm bolt and nut 1.8-2.5
4 10mm bolt and nut 3.0-4.0
5 12mm bolt and nut 5.0-6.0
6 5mm screw 0.35-0.5
7 6mm screw 0.7-1.4
8 6mm flange bolt and screw 1.0-1.4
9 7mm flange bolt and screw 1.0-1.4
10 8mm flange bolt and screw 2.0-3.0
11 10mm flange bolt and screw 3.0-4.0
