PGO G-MAX200 - Page 71

9.Remove the Cylinder and the gasket.
10.Remove the c type clip on the piston and piston pins by the nipper.
•Take off piston.
11.Dismatling of the piston ring Take off the first piston ring then the second ring.
12.When assembling please reverse the procedures of dismantling.
Locking torque:
M7:1.0-1.4kg-m
M6:1.0-1.2kg-m
Opening end of piston ring
