0.9 BDL3245E/BDL4245E/BDL4645E
32”/42”/46” FHD LCD PUBLIC DISPLAY
2011-07-01 PHILIPS Page 12 of 38
MMD Con
idential
INPUT: Select input from HDMI, DVI-D, VGA, COMPONENT, S-VIDEO, VIDEO, OPS
MUTE: Switch audio on/off.
POWER: It is a soft power switch and not a main disconnection device. Main disconnection shall be accomplished by
physically removing the power cord from the display.
2.6.2 Front controls
• LED indicator -
LED Status Power Status LED behavior
LED Active
Normal ON Green
Sleeping Green/blue
RC command Blinking
Schedule off
Green blinking/red
If ON TIME is "--:--", the
Green is not blinking.
Standby/DC power off Red
LED Not-active Switch off Blank
• RC sensor – Receiver for Display control, transmitter for data cloning.
• Below 300-500 cd/m2
Operation Angle RC operational distance
Please 0° (for H & V) ≥ 10m (control from the front)
20° (for H & V) ≥ 5m (control from the front)
45° (for H only) ≥ 2m (control from the front)
• Remote Control – Philips protocol.
Philips protocol is used for remote control communication.
