Philips BDL3245E/00 - Key Board; CNPC Board

64
6.5 Key Board (715G4719K01000004K)
Remark: Parts position can be searched by using FIND function in PDF.
6.6 FAN Board (715G3587T01000004M)
Remark: Parts position can be searched by using FIND function in PDF.
KEY_PWR
R001
330R +-1% 1/10W
KEY_ADC2
KEY_ADC1
PWR EXIT UP DOWN + - INPUT RESET
R002
680R 1/10W 1%
R003
2Kohm 1/10W +/-1%
R004
330R +-1% 1/10W
R005
680R 1/10W 1%
R006
2Kohm 1/10W +/-1%
SW008
SW
SW007
SW
SW006
SW
SW005
SW
SW004
SW
SW003
SW
SW002
SW
SW001
SW
1
2
3
4
65
CN001
CONN
1
2
CN701
CONN
Q701
PMBS3906
