0.9 BDL3245E/BDL4245E/BDL4645E
32”/42”/46” FHD LCD PUBLIC DISPLAY
2011-07-01 PHILIPS Page 30 of 38
MMD Con
f
idential
7.15 Product Dimension / Weight
BDL3245E
• Unit dimension (without stand) - 773.6L x 468.3W x 116H mm
• Unit dimension (with stand) - 773.6L x 505.1W x 239.8H mm
• Packed unit dimension (carton) - 879.6L x 670.4W x 252Hmm
• Net weight (without stand) - 12.8 kg
• Gross weight - 17 kg
BDL4245E
• Unit dimension (without stand) - 991.6 x 584 x 115.5mm
• Unit dimension (with stand) - 991.6 x 621 x 329.6mm
• Net weight (without stand) - 22 kg
• Gross weight - 27.5 kg
BDL4645E
• Unit dimension (without stand) - 1091.1 x 645.7 x 133mm
• Unit dimension (with stand) - 1091.1 x 681.7 x 329.6mm
• Net weight (without stand) - 24.6 kg
• Gross weight - 31 kg
7.16 Transportation
Packaging and wrapping shall be sufficient to protect the product against damage or loss
during shipment from the supplier to the destination specified in the purchase order. All
packaging materials are subject to test and evaluation per XTN-0009,UAN-D636.
Packaging unit should be protected by corner protector on 4 corners, don’t use surrounding
cardboard.
7.16.1 Transportation packages
The overall test sequence is: vibration test, drop test and when applicable cold drop test.
The sequential tests have to be carried out using the same packaging.
Vibration, drop test should be performed at ambient temperature (20°C to 23
o
C) and
relative humidity (40% to 65%).
7.16.2 Transportation test procedures
Transportation test specification refers to XTN-0009.pdf, for all regions.
Packaging test
• Vibration and drop or cant-drop test (UAN-D 1534/01)
• Vibration and cold/drop test (UAN-D 1534/01, UAN-D 1534/02 and UAN-D 636)
• Vibration, bump and drop test only for China & India(UAN-D 1534/02)
• Multiple drop test only for China & India(UAN-D 1534/02)
• Bump test only for China & India(UAN-D 1534/02)
