0.9 BDL3245E/BDL4245E/BDL4645E
32”/42”/46” FHD LCD PUBLIC DISPLAY
2011-07-01 PHILIPS Page 18 of 38
MMD Con
idential
• RJ-45 input: Differential Signal used as LAN control function.
RJ-45 connector pin assignment:
Pin Signal Assignment Pin Signal Assignment
1 Transmit+ 2 Transmit-
3 Receive+ 4 N/A
5 N/A 6 Receiver–
7 N/A 8 N/A
Features：
8 pin RJ45 (8P8C) female connector
Shield With LED lights
Meets or exceeds IEEE 802.3 standard for 100 Base-T.
3000 times.
Suitable for CAT 5 & 6 Fast Ethernet Cable or better UTP
RJ-45 needs to be matched FCC/UL standard.
Comply with RoHS requirements-whole part No Cd, No Hg, No Cr6+, No PBB
and PBDE and No Pb on external pins.
Durability: 3,000 Insertions at least (Mating Force: 5 lbs./2.268 kgs.)
Operating temperature range: -10℃ to +50 .℃
Storage temperature range: -25 to +125℃℃
Note：HDMI、DVI、VGA、CVBS、S-Video cable length 1.8M
RS-232 cable length 30M, LAN cable length 80M
3. VISUAL PERFORMANCE
3.1 LCD Module Characteristics
32”:
Vendor
First Panel Second Panel
Panel Type Number
LGD/LC320WUN-SCB1_CAS
Module Dimensions
(mm)
31.55 inches(801.31mm) diagonal
Display Area (H x V)
698.4mm(H)x 392.85mm(V)
Aspect Ratio
16:9
Pixel Format
1920 horiz.by 1080 vert. Pixels,RGB
stripe arrangement
Pixel Pitch (mm)
0.36375mmX0.36375mm
Color Pixel Arrangement
RGB stripe arrangement
Display Operating Mode
Transmissive mode,Normally black
Color Depth
10bit(D), 1.06Billon colors
Gamut (color saturation) 72%
Luminance (cd/m^2)
500(type),400(min)
Response Time
G TO G 5max(type), 8ms(max
Contrast Ratio
1450(type),1000(min)
View Angle (CR > 10)
up/down:89(min)
Power Consumption
105W(type);115W(max)
Module Weight
5.5Kg(Typ);6.9Kg(max)
