Philips BDL3245E/00 - Power Board Schematic

53
6.2 Power Board
BDL3245E (715G5082P01000003H)
Remark: Parts position can be searched by using FIND function in PDF.
C9902
220pF 250V
C992
220pF 250V
RV902
Varistor
!
!
!
!
!
!
!
!
!
!
R902
390K 1/4W
R901
390K 1/4W
!
!
!
!
!
!
!
C991
220pF 250V
2
1
3
4
-
+
BD901
D15XB80
SG901
NC
SG902
NC
F902
NC
1
4
2
3
L903
2.0MH
C9901
220pF 250V
C994
0.47uF
NC
1
D1
2
D1
3
NC
4
NC
5
D2
6
D2
7
NC
8
IC911
CAP004DG
!
!
F901
6.3A 250V
1
4
2
3
L902
20.0MH
1
4
2
3
L901
20.0MH
RV901
C993
0.47uF
BO
R+
1
2
3
4
CN901
CONN
